Powerful, cordless machine with a long tool
For the first time, you can use the TruTool PN 201 battery machine cordlessly to cut sheet thicknesses in mild steel up to 2 mm, even in the case of doubled sheets. The extraordinarily strong machine with a long tool is particularly well-suited to deep trapezoidal sheets of up to 162 mm. The tool can be rotated 360° on the spot. The cutting direction, punch, and die carrier can be changed quickly, without the need for tools. For example, with the 4 Ah rechargeable battery you can therefore cut up to 54 meters in mild steel and a sheet thickness of 1 mm. You can choose from various tool depths to broaden the areas of application.
Cross-manufacturer rechargeable battery system for leading power tool brands. 100% compatibility in the 18-volt class.
Almost unlimited service life, virtually wear-free and hardly any maintenance required. Battery performance per charge is also increased.
Primarily for processing profile depths of up to 6.37 in. Also well-suited to C-L-U profiles.
You can adjust the working direction through 360° in steps of 45° easily, without the need for tools.
The following consumables and the corresponding accessories are included in the scope of delivery.
1 unti 2260206
1 unti 2260207
1 unti 1884927
1 unti 1750692
1 unti 2260208
1 unti 0359907
1 unti 2598811
1 unit, DE/CH version: 2569784
1 unit, GB version: 2569786
1 unit, USA version: 2569785
1 unti 1770890
Find the right consumables and accessories for your machine here.
The light metal gear head's ingenious design is specially adapted to the low voltage battery technology. Decoupling the motor pinion from the motor minimizes energy loss and ensures even higher performance per battery charge.
The powerful BL motor generates higher torques than conventional motors, requires less power and generates hardly any heat. This has a positive effect on the battery life and lets you get the most out of every battery charge. Additional advantage: The service life of a BL motor is almost unlimited because they work without carbon brushes and therefore no mechanical friction occurs. The result: almost wear-free motors and hardly any maintenance.
Compact and powerful
The 18V rechargeable battery tool has a lightweight design enabling fatigue-free working. The soft grip ensures safe and low-vibration working. All TRUMPF rechargeable battery tools are also available as stand-alone versions, i.e. without rechargeable batteries and recharger. If you already have CAS batteries available, you then have the option to save on resources and cut costs.
Optimal working speed
You can use the speed controller to adjust the working speed to suit the individual cutting task. It is extremely efficient if you work in accordance with the predefined cutting lines or a template. It is also well-suited to frequent processing of radii and stainless steel. The electronic overload protection offers yet another notable benefit.
TruTool PN 201 18V LiHD rechargeable battery
|Maximum sheet thicknesses|
|Maximum sheet thickness, steel 400 N/mm²||2 mm|
|Maximum sheet thickness, steel 600 N/mm²||1.5 mm|
|Maximum sheet thickness, steel 800 N/mm²||1 mm|
|Maximum sheet thickness, aluminum up to 250 N/mm²||3 mm|
|Smallest radius||50 mm|
|Working speed||1.9 m/min|
|Starting hole diameter||24 mm|
|Weight (with 4 Ah rechargeable battery)||2.4 kg|
This product range and information may vary depending on the country. Subject to changes to technology, equipment, price, and range of accessories. Please get in touch with your local contact person to find out whether the product is available in your country.
