The alternative for mild steel and aluminum
In contrast to the TruTool TKF 1100, the TKF 1101 is used for mild steel and aluminum applications. The gearbox, which has been specifically adapted for this area of application, increases the stroke rate and provides you with perfect chamfer quality. The machine can be positioned in the middle of the sheet. It is easy to apply weld seams to straight sheets, tubes, interior cutouts, and curved edges.
The TruTool TKF 1101 was specially designed for use with mild steel and aluminum.
You can rotate the cutting direction by 90° to the right or left.
Ideal for applications where the machine is tilted 90°.
It is quick and easy to adjust the optimal settings for the chamfer height and sheet thickness.
The following consumables and the corresponding accessories are included in the scope of delivery.
1 unit 1299028
1 unit 1279590
1 unit 0067857
1 unit 0103387
1 unit 1369906
1 unit 1411767
1 unti 1763686
Find the right consumables and accessories for your machine here.
TruTool TKF 1101 30° bevel angle
TruTool TKF 1101 37.5° bevel angle
TruTool TKF 1101 45° bevel angle
|Maximum chamfer lengths|
|Max. chamfer length, steel 400 N/mm²||11 mm||11 mm||11 mm|
|Max. chamfer length, steel 600 N/mm²||9 mm||9 mm||9 mm|
|Max. chamfer length, steel 800 N/mm²||6 mm||6 mm||6 mm|
|Smallest radius||40 mm||40 mm||40 mm|
|Working Speed||2 m/min||2 m/min||2 m/min|
|Stroke rate with nominal load||340 / 440 1/min||340 / 440 1/min||340 / 440 1/min|
|Nominal power consumption||1600 W||1600 W||1600 W|
|Sheet Thickness||3 mm - 25 mm||3 mm - 25 mm||3 mm - 25 mm|
|Weight without cable||10 kg||10 kg||10 kg|
This product range and information may vary depending on the country. Subject to changes to technology, equipment, price, and range of accessories. Please get in touch with your local contact person to find out whether the product is available in your country.
